Description
Cast Iron Taco 007-F5 Circulator Pump is the most popular hydronic circulator sold today. Features a field serviceable cartridge design and provides a quiet, efficient operation and unmatched reliability. It has a self-lubricating, maintenance-free design and it’s flow parameters make it an ideal circulator for a wide range of hydronic applications.
Taco 007-F5 Circulator Pump is a cartridge style, maintenance free, wet-rotor, in-line, single stage circulator pump. It is designed for quiet operation in Hydronic heating, Radiant heating and Hydro-Air fan coils.
Applications:
- Hydronic Heating/Cooling;
- Radiant Heating;
- Zoning with Pumps;
- Hydro-Air Fan Coils;
- And others
Cross-References:
- Grundfos UP15-42F/R, UPS15-58FC spd 2;
- B&G NRF-22.
Technical Specifications:
- Flow Range: 0 – 23 GPM;
- Head Range: 0 – 10 Feet;
- Minimum Fluid Temperature: 40˚F (4˚C);
- Maximum Fluid Temperature: 240°F (115˚C);
- Maximum Working Pressure: 125 psi;
- Connection Sizes: 3/4″, 1″, 1-1/4″, 1-1/2″ Flanged;
- Voltage: 115V;
- Hertz: 60Hz;
- Phase: 1;
- Amps: 0.71A;
- HP: 1/25HP;
Warranty:
3-year manufacturer’s warranty.
