008 Circulator Pump w/ IFC, 1/25 HP, 115V

Description

Cast Iron Taco 008-F6-3IFC Circulator Pump with Integral Flow Check (IFC) is designed to reduce installation costs when zoning with “00” circulators on hydronic or radiant heating, hydro-air fan coils or closed-loop solar heating systems. A built-in Integral Flow Check (IFC) of the Taco 008-F6-3IFC eliminates the need for purchase and installation of an additional flow check valve.

Applications:

• Hydronic Heating/Cooling
• Radiant Heating
• Zoning with Pumps
• Mixing Stations
• Hydro-Air Fan Coils
• And others

Cross-References:

• Grundfos UP15-42FC, UPS15-58FC @ spd 2

Technical Specifications:

• Flow Range: 0 – 12.5 GPM;
• Head Range: 0 – 15 Feet;
• Minimum Fluid Temperature: 40˚F (4˚C);
• Maximum Fluid Temperature: 240°F (115˚C);
• Maximum Working Pressure: 125 psi;
• Connection Sizes: 3/4″, 1″, 1-1/4″, 1-1/2″ Flanged;
• Voltage: 115V;
• Hertz: 60Hz;
• Phase: 1;
• Amps: 0.79A;
• HP: 1/25HP;

Warranty:
3-year manufacturer’s warranty.
