Belimo LF24 Damper Actuator, 35 in-lb [4 Nm], Spring return, AC/DC 24 V, On/Off

Name: Belimo LF24 Damper Actuator, 35 in-lb [4 Nm], Spring return, AC/DC 24 V, On/Off
SKU: 7563856937198
Availability: InStock

Actuator Type: Spring return

Angle of Rotation: 95

Control Type: On/Off

Degree of Protection: IP54, NEMA 2

Direction of Rotation (Fail-Safe): Reversible with cw/ccw mounting

Electrical Connection: Cable

Power Consumption (Holding): 2.5 W

Power Consumption (Running): 5 W

Running Time (Fail-safe): <25 s

Running Time (Motor): 75 s / 90°

Safety Function: YES

Shaft Diameter: 3/8…1/2″ round, centers on 1/2″

Torque: 35 in-lb [4 Nm]

Voltage AC/DC: AC/DC 24 V
