Honeywell TH1100DH1004/U – Thermostat Pro 1000 Non Programmable

Product Specifications:

• Application – Heat Only
• Dimensions – 3 7/16 in. High x 4 10/16 in. Wide x 1 3/16 in. Deep
• Mounting – Horizontal
• Electrical Rating – 20 to 30 Vac or 750 mV
• Frequency – 50 Hz; 60 Hz
• Stages – 1 Heat
• Power Method – Dual Powered: Battery or Hardwire
• Setting Temperature Range (F) – Selectable Heat: 40 F to 90 F or 35 F to 90 F
• Setting Temperature Range (C) – Selectable Heat 4.5 C to 32 or 1.5 C to 32 C
• Cycles Per Hour – Heating 2-6 CPH
• Heat Current – 0.02 A to 1.0 A running
