Description

Honeywell TH1100DV1000/U – Thermostat Pro 1000 Non Programmable

Product Specifications:

• Application – Heat Only
• Dimensions – 4 11/16 in. High X 2 7/8 in. Wide X 1 1/8 in. Deep
• Mounting – Vertical
• Electrical Rating – 20 to 30 Vac or 750 mV
• Frequency – 50 Hz; 60 Hz
• Stages – 1 Heat
• Power Method – Dual Powered: Battery or Hardwire
• Setting Temperature Range (F) – Selectable Heat: 40 F to 90 F or 35 F to 90 F
• Setting Temperature Range (C) – Selectable Heat 4.5 C to 32 or 1.5 C to 32 C
• Cycles Per Hour – Heating 2-6 CPH
• Heat Current – 0.02 A to 1.0 A running

Installation Materials
