Description
TDLX 2010B torch carrier outfit kit includes: PL-8A (self-lighting) and A-3 (standard) air acetylene tips, G4 torch handle, AR-B (CGA 520 connection) regulator, AH-12 hose (12ft), B-tank key and durable 2-wheeled roller tote case with multiple storage compartments. Gas cylinder not included. See Brochure under “Literature” tab for detailed tote features .
Technical Specifications:
- Fuel Type: Air Acetylene
- Tank Connection: B
- Valve Position: Rear
- PL-8A tip size: 5/16″ (7.9 mm)
- PL-8A Pipe sizes (Soft Solders): 1″ to 2″ (25-50 mm)
- PL-8A Pipe sizes (Silver Brazes): 1/2″ to 1″ (13-25 mm)
- PL-8A tip gas flow: 7 scfh @ 14 psi (0.21 cu m/hr @ 0.9 bar)
- A-3 tip pipe sizes (Soft Solders): 1/4″ to 1″ (6.4 – 25 mm)
- A-3 tip pipe sizes (Silver Brazes): 1/8″ – 1/2″ (3.2 – 13 mm)
- A-3 tip gas flow: 3.6 scfh @ 14 psi (0.108 cu m/hr @ 0.9 bar)
- Tank fit: type “B” acetylene cylinders or CGA 520 connection. Cylinder tank not included.
Warranty:
3 Year Limited Warranty
